Khoom kim heev Steel Framing Tsev
Steel kem: Q235 Steel, 100 * 100 * 2.5 square raj, alkyd painting, ob zaug primer xim & ob zaug tiav xim
Hlau ru tsev truss: C100 * 40 * 15 * 2.0, vuam thiab galvanized
ru tsev thiab phab ntsa purlin: C1 00 * 40 * 15 * 2.0, galvanized
Hla bracing: Q235 Steel, L40 * 3 lub kaum sab xis steel, alkyd painting, ob zaug primer xim & ob zaug tiav xim
Khoom Taw qhia
Khoom kim heev Steel Framing Tsev cov ntaub ntawv xaiv | ||
Hom | Nrog los yog tsis muaj steel chassis | Hom ib: tsis muaj steel chassis, tsim ntawm pob zeb sawb foundation |
Dab neeg | Ib zaj dab neeg lossis ob zaj dab neeg lossis peb zaj dab neeg muaj | |
Ncej system | Steel kem | Q235 Steel, 100 * 100 * 2.5 square raj, alkyd painting, ob zaug primer xim & ob zaug tiav xim |
Steel ru tsev truss | C100*40*15*2.0, vuam thiab galvanized | |
Ru tsev thiab phab ntsa purlin | C100 * 40 * 15 * 2.0, galvanized | |
Hla bracing | Q235 Steel, L40 * 3 lub kaum sab xis steel, alkyd painting, ob zaug primer xim & ob zaug tiav xim | |
Chemical ntsia liaj qhov rooj | M16, tshuaj bolts | |
Ordinary ntsia liaj qhov rooj | 4.8S, galvanized hlau | |
Steel chassis lossis 1st pem teb system | Main beam | HN250 * 125 * 5.5 * 8, Q235 Hlau, alkyd painting, ob zaug primer xim & ob zaug tiav xim |
Secondary beam | C100*40*15*2.0 galvanized | |
Pem teb qauv board | 18/20mm plywood thiab fiber ntau cement board | |
Pem teb | PVC pem teb tawv thiab ceramic vuas yog muaj | |
Phab ntsa thiab ru tsev system | Phab ntsa vaj huam sib luag | Sandwich vaj huam sib luag: Pob zeb wool, iav ntaub plaub, EPS, PU muaj |
Lub vaj huam sib luag | Sandwich vaj huam sib luag: Pob zeb wool, iav ntaub plaub, EPS, PU muaj | |
Qab nthab system | Chav qhuav | 600 * 600 * 6mm gypsum board, nrog lub moj khaum |
chav ntub dej | 600 * 600 * 5mm calcium silicate board, nrog lub moj khaum | |
Qhov rooj thiab qhov rais system | Qhov rooj | Hluav taws kub resistant steel ib leeg/ob qhov rooj, qhov rooj thaum muaj xwm ceev nrog ceeb bar, txhuas iav qhov rooj, MDF qhov rooj muaj |
Qhov rai | PVC, Aluminium zawv zawg qhov rais nrog ib qho / ob chav glazed iav, nrog yoov tshaj cum, nrog louver muaj | |
Hluav taws xob thiab kav dej system | Hluav taws xob units | Hluav taws xob xaim, conduit, qhov (socket), hloov, lub teeb, faib lub thawv |
Cov chav huv huv | Da dej, txee dai khaub ncaws, dab dej, kav dej | |
Qhov zoo
Lub neej rau cov qauv: 50 xyoo.
Av qeeg tsis kam: Max. ntau tshaj 8 qib.
Cua tsis kam: max 64m / s.
Hluav taws kub tsis kam: tag nrho cov khoom siv tuaj yeem tiv taus hluav taws.
Snow resistance: max 2.9KN / m² raws li xav tau
Thaum tshav kub kub rwb thaiv tsev: 100 hli nyob rau hauv thickness yuav phim 1 m thickness ntawm cib ntsa.
High acoustic rwb thaiv tsev: 60db ntawm sab nrauv phab ntsa 40db ntawm sab hauv phab ntsa
Kev tiv thaiv kab: Dawb los ntawm kev puas tsuaj los ntawm kab, xws li ntsaum dawb
Kev ua pa: kev sib xyaw ua ke ntawm qhov cua los yog cua tshuab ua kom cov cua hauv tsev tshiab thiab huv si
Ntim thiab xa khoom: 140SQM / 40'HQ thawv rau cov qauv nkaus xwb thiab 90SQM / 40'HQ thawv rau cov qauv nrog cov khoom siv kho kom zoo nkauj.
Kev teeb tsa: qhov nruab nrab yog ib tus neeg ua haujlwm ib hnub nruab ib SQM.
Daim ntawv qhia kev teeb tsa: xa engineer los qhia rau ntawm qhov chaw.
Daim ntawv thov
Lub teeb steel nyob hauv tsev;
Lub teeb steel tsev tsev;
Lub teeb steel pheej yig lub tsev;
Lub teeb steel khoom kim heev villa;
Lub teeb steel qauv tsev noj mov;
Lub teeb steel ncej chaw ua haujlwm lub tsev
Lub teeb steel ncej tsev so tsev;
Lub teeb steel ncej tsev kawm ntawv;
Lub teeb steel qauv tsev kho mob lub tsev;
Lub teeb steel qauv vocational resort tsev;
Lub teeb steel prefab granny tiaj tus;
Lub teeb steel ncej modular pod;
Lwm lub tsev prefab lub teeb yuag;
Tej yaam num
Indonesia:
PT Merdeka chaw pw hav zoov-288 chav nrog ensuite;
AMMAN chaw pw hav zoov -480 chav nrog ensuite;
Chile:
FRIOSAN txias cia—1600sqm Khoom kim heev Steel Framing Tsev nrog ob pem teb chaw ua hauj lwm cheeb tsam, nyob rau hauv-depended noj mov thiab nkag mus rau hauv chav tsev
Reduccion cas
Casa Laguna Verde-156sqm ob pem teb 4 Bedroom Prefabricated Tsev
Austrian:
Polyfit Rhiav thiab chaw ua hauj lwm lub tsev - nyob rau hauv tag nrho ib ncig ntawm 2000sqm, muab steel qauv, lub teeb gauge steel ncej thiab ob txhais tes shipping thawv;
Philippines:
SCPA Rhiav-3200sqm nrog Ob Pem Hauv Paus Pob Thawv Hauv Tsev
SG Eco Rhiav-3600sqm warehouse nrog ob chav ua haujlwm hauv 250sqm,
Iriga Hoobkas,
BBL Camp - 24 chav pw pw hav zoov nrog cov kev pabcuam pej xeem xws li chav noj mov, chav gym;
Maria De Sio Resort -320sqm
SMMCI Camp—1300sqm chaw ua haujlwm lub tsev tsim los ntawm lub tsev ntim khoom thiab 2600sqm warehouse
PNG:
PNG pob zeb Kev Txhim Kho—13 steel qauv warehouse nyob ib ncig ntawm 1500sqm txhua;
Virgin Island: 10000sqm Distribution center
New Caledonia:
Alain's warehouse-tsib pem teb warehouse tsev nrog cargo nqa, nyob rau hauv tag nrho 1750sqm
Le Tigre Warehouse-peb warehouse nrog ramp, tag nrho 3700sqm
Mozambique:
Nakala Resort - 32 units ntawm lub teeb ntsuas steel lub tsev raws li lub puam sab nraum zoov;
Tonga: Tonga Fais Fab - 3600 sqm
Reunion Island: ARC{0}/19 Lub Tsev Project—240sqm Khoom kim heev Steel Framing Tsev
FAQ
Koj puas muab kev pabcuam rau ntawm qhov chaw?
1) Tsuas yog tej yaam num loj muab kev pab cuam installation
2) Cov dej num dav dav, peb tuaj yeem muab kev qhia kev txhim kho raws li cov neeg siv khoom thov.
3) Tus nqi saib xyuas kev teeb tsa: 150USD / hnub, tus neeg siv khoom yuav tsum lav tus nqi mus ncig, chaw nyob, tus nqi txhais lus, thiab ua kom cov neeg ua haujlwm noj qab haus huv thiab nyab xeeb.
Koj lub sijhawm xa khoom yog dab tsi?
Tus neeg muag khoom yuav lees paub lub sijhawm raws li, kev txiav txim loj yuav tsum sib txuas lus nrog kev tswj hwm kev txiav txim ua ntej. Feem ntau, lub sijhawm xa khoom yog 45 hnub tom qab tau txais qhov tso nyiaj. Lub sij hawm xa tuaj loj yuav tsum tau teem caij sib cais.
Yuav ua li cas tswj qhov zoo ntawm koj cov khoom?
a. Kev tsim qauv zoo: xav txog cov teeb meem uas yuav tshwm sim ua ntej thiab muab cov qauv tsim qauv zoo.
b. zoo ntawm cov khoom siv raw: xaiv cov khoom tsim nyog
c. Kev tsim khoom zoo: cov txheej txheem tsim khoom, cov neeg ua haujlwm paub txog, kev tshuaj xyuas nruj.
Yuav daws cov teeb meem zoo li cas?
Warranty yog 3 xyoos. Tsis pub dhau lub sijhawm lav, HANGZHOU XIXI BUILDING CO., LTD yuav lav tag nrho cov teeb meem zoo los ntawm kev tsim khoom.
Yog tias muaj kev pabcuam meej meej ntawm koj cov khoom? Yog muaj, ntev npaum li cas?
Raws li kev nyab xeeb thiab ib puag ncig, steel qauv tag nrho lub tsev 10 xyoo, cov qauv tseem ceeb 15 xyoo, tiv thaiv qhov system 10 xyoo.
Dab tsi tsim koj muaj nyob rau hauv cov huab cua sib txawv (Yuav ua li cas cov khoom yuav coj mus rau txawv huab cua)?
Lub zog cua hauv cheeb tsam: txhim kho cov cua-tiv taus lub peev xwm ntawm cov qauv sab hauv.
Cov cheeb tsam txias: nce lub thickness ntawm phab ntsa, los yog siv cov khoom siv rwb thaiv tsev zoo, txhim kho kev tiv thaiv kev muaj peev xwm ntawm cov qauv.
Cov cheeb tsam corrosion siab: siv cov khoom siv tiv thaiv corrosion, los yog xim pleev xim rau txheej.
Yuav ua li cas koj lav qhov zoo ntawm Cov Khoom kim heev Steel Framing Tsev?
A: Kev ua tau zoo yog yav tom ntej. Kev ua tau zoo yog qhov tseem ceeb tshaj plaws.
Peb muaj tsib tus neeg QC pab pawg tshuaj xyuas kev tsim khoom txhua hnub, lawv yuav ua raws li lub khw kos duab nruj me ntsis thiab tshawb xyuas txhua feem / project thaum pib, nruab nrab thiab rau cov khoom tiav.
Peb tuaj yeem sib sau ua ke qee chav nyob hauv peb lub Hoobkas rau qee qhov tshwj xeeb customized ua haujlwm kom paub tseeb tias txhua yam zoo txaus.
