Me Prefab Tsev
Tag nrho cov qhov ruaj khov thiab cov yeeb nkab qhov yog pre-punched, 2-3 cov neeg ua haujlwm tuaj yeem ua tiav qhov kev teeb tsa. (Txuag 70 feem pua cov nqi zog, txo 10 feem pua lub sij hawm tsim kho, ceev 30 feem pua ntawm cov txheej txheem tsim kho)
Khoom Taw qhia
Main Ncej rau Me Prefab Lub Tsev | ||
Lub teeb steel keel ncej | kg | G550 Al-Zn Galvanized, AZ150 |
Lub teeb steel keel ncej | kg | Q345 galvanized hlau |
Lub teeb steel keel ncej | kg | G550 Al-Zn Galvanized, AZ150, BlueScope hom |
Steel qauv | kg | Q235, Hwv |
Kho qhov system | ||
Ru Tsev System | ㎡ | 0.5mm Xim Hlau Glazed Pobzeb ntxiv rau 30mm XPS Rwb Thaiv Tsev Strip plus Ntoo batten ntxiv rau Lub Tsev Moisture-proof Tsev qhwv ntxiv rau 12mm OSB board ntxiv rau 150mm iav Fiber rwb thaiv tsev (Glass Fiber Owens Corning) |
㎡ | ||
m | ||
㎡ | ||
㎡ | ||
㎡ | ||
Sab nrauv phab ntsa System | ㎡ | 12 hli Eterpan planks ntxiv rau 30mmXPS Rwb thaiv tsev Sawb ntxiv Ntoo batten ntxiv rau 12 hli OSB Board ntxiv rau lub ru tsev Moisture-proof Housewrap ntxiv rau 12 hli Jason Plaster Board (Siv ib txheej 12 hli Fiber Cement Board es tsis txhob 12 hli Plaster Board rau sab hauv ntawm sab nrauv phab ntsa hauv chav dej) ntxiv rau 12 hli OSB board (Tsuas yog rau chav ua noj phab ntsa) |
㎡ | ||
m | ||
㎡ | ||
㎡ | ||
㎡ | ||
㎡ | ||
㎡ | ||
Sab Hauv Phab Ntsa System | ㎡ | 12 hli Jason Plaster Board ntxiv rau 100 hli iav Fiber rwb thaiv tsev (Owens Corning) ntxiv rau 12 hli Jason Plaster Board (Ib txheej Fiber Cement Board es tsis txhob Plaster Board rau Phab Ntsa hauv Chav Dej) |
㎡ | ||
㎡ | ||
Phab ntsa Ceramic Vuas rau Chav Dej | ㎡ | 300 * 450mm Phab ntsa pobzeb |
Pem Teb Board | ㎡ | 600 * 600mm (Ceramic, tsis suav nrog chav dej) |
㎡ | 300 * 300mm (Ceramic, tsuas yog suav nrog chav dej & chav dej) | |
㎡ | Ceramic pobzeb skirting kab | |
Floor deck plus stairs | ㎡ | 3m thickness, 1m dav |
㎡ | 18 hli Fiber Cement Board | |
㎡ | 100mm iav Fiber rwb thaiv tsev | |
㎡ | 12mm OSB board | |
㎡ | 300 * 300mm ceramic pobzeb (Anti-skid) | |
Qab nthab | ㎡ | 6 hli Fiber Cement board |
㎡ | 9 hli Jason Plaster Board Ceiling (xws li Thawj thiab Secondary Keel) | |
Qhov rai (AU, UL lossis EU tus qauv) | Aluminium Alloy Ncej Ob Chav iav Qhov rai, ua raws li AS2047 cov qauv, iav ua raws li AS / NZS2208, AS1288. | |
㎡ | ALU. Qhov rai zawv zawg | |
Qhov rooj | pc ua | W920 * H2340mm ALU. viav vias qhov rooj |
pc ua | W820 * H2340mm MDF qhov rooj | |
pc ua | W820 * H2340mm MDF zawv zawg qhov rooj | |
Flashing & Ntug Trimming Fittings | ㎡ | Self-bending Xim Steel Sheet (Rov Ridge, Gable Phab Ntsa Wrapping Npog) |
Xim Steel Fascia | m | Xim Steel Verge Board (nrog Brackets) |
Aluminium Alloy Profiles | kg | Ntug npog rau kaum, qhov rooj & qhov rais, sab hauv kaum. |
12 hli Fiber Cement Board | ㎡ | kho kom zoo nkauj sab nraum zoov |
Qhov zoo
Yooj yim rau nruab:
Tag nrho cov qhov ruaj khov thiab cov yeeb nkab qhov yog pre-punched, 2-3 cov neeg ua haujlwm tuaj yeem ua tiav qhov kev teeb tsa. (Txuag 70 feem pua cov nqi zog, txo 10 feem pua lub sij hawm tsim kho, ceev 30 feem pua ntawm cov txheej txheem tsim kho)
Hluav taws kub thiab kab tiv thaiv:
Tag nrho cov keels yog galvanized, tsis tas yuav siv tshuaj tua kab, preservative los yog kua nplaum. Lub phab ntsa system yog ntim nrog cov ntxhia wool thiab steel ncej system yog fireproof.
Prefabricated:
Peb lub Hoobkas yuav xub tsim tag nrho cov keels, tom qab ntawd prefabricated phab ntsa thiab tom qab ntawd ntim lawv.
Thaum tshav kub kub rwb thaiv tsev:
Cov txheej txheem steel phab ntsa tsis cuam tshuam los ntawm qhov kub thiab av noo kom ntau qhov cua sov thiab cua txias zog nyob hauv tsev, yog li ntau lub zog yuav raug cawm. (100 hli hauv thickness tuaj yeem phim 1 m thickness ntawm cib phab ntsa, 2-5 lub sij hawm zoo dua li cov qauv)
Cua & seismic tsis kam:
Cov khoom sib txuas thiab hardness ntawm cov hlau nws tus kheej tuaj yeem siv los tiv thaiv seismic thiab nag xob nag cua. (Cov qauv tseem ceeb tuaj yeem tiv taus 230km / h cua thiab siab dua 8 qib av qeeg) Steel lub zog siab ua rau nws lub tsev zoo tshaj plaws los tiv thaiv lub zog seismic.
Artistic thiab xis nyob:
Sab hauv kho kom zoo nkauj yog raws li koj xav tau. Thiab huab cua zoo yog qhov zoo.
Kev txuag hluav taws xob thiab kev tiv thaiv ib puag ncig:
Tsuas yog 1 feem pua kev tsim khoom pov tseg. Cov nqi rov ua dua ntawm cov hlau nce mus txog 70 feem pua. mus txog rau thaum lub tsev lub neej dhau lawm, cov hlau tseem siv tau.
Lifetime rau cov qauv:
Lub neej ntawm Me Prefab Lub Tsev yog ntau tshaj 70 xyoo.
Hluav taws kub tsis kam:
Txhua yam khoom siv tuaj yeem ua rau hluav taws kub.
Snow resistance:
Max. 2.9 KN / m2raws li xav tau
High acoustic rwb thaiv tsev:
60db ntawm sab nrauv phab ntsa 40db ntawm sab hauv phab ntsa
Packing thiab shipping:
600SQM / 40'HQ thawv rau cov qauv nkaus xwb thiab 200SQM / 40'HQ thawv rau cov qauv nrog cov ntaub ntawv zoo nkauj.
Daim ntawv thov
Lub teeb steel nyob hauv tsev;
Lub teeb steel tsev tsev;
Lub teeb steel pheej yig lub tsev;
Lub teeb steel khoom kim heev villa;
Lub teeb steel qauv tsev noj mov;
Lub teeb steel ncej chaw ua haujlwm lub tsev
Lub teeb steel ncej tsev so tsev;
Lub teeb steel ncej tsev kawm ntawv;
Lub teeb steel qauv tsev kho mob lub tsev;
Lub teeb steel qauv vocational resort tsev;
Lub teeb steel prefab granny tiaj tus;
Lub teeb steel ncej modular pod;
Lwm lub tsev prefab lub teeb yuag;
Tej yaam num
| Lub npe qhov project | Damien lub tsev | ||
| Sijhawm tiav | Xyoo 2017, Kaum Hli. | ||
| Qhov Chaw Qhov Chaw | Coron Philippines | ||
| Lub tsev | 280 m² os | ||
| Qhov project piav qhia | Ob chav Me Me Prefab Lub Tsev, hauv qab daus siv los ua lub rooj cob qhia me me rau Damien los kho lub Speedboat. Lub tsev no nyob hauv BBL chaw so. | ||
| Lub npe qhov project | Raul's Appartment | ||
| Sijhawm tiav | Xyoo 2019, Nov. | ||
| Qhov Chaw Qhov Chaw | Coron Philippines | ||
| Lub tsev | 430m wb | ||
| Qhov project piav qhia | Tsim thiab muab tag nrho cov ntaub ntawv, muab cov lus qhia kev teeb tsa thiab kev txhawb nqa online, kuj muaj tus khub tsim kho zoo nyob ntawd los tswj tag nrho qhov project zoo heev. |
| Lub npe qhov project | Qhov project Number 1 Homes | ||
| Sijhawm tiav | Xyoo 2015, Lub Rau Hli | ||
| Qhov Chaw Qhov Chaw | Christchurch NZs | ||
| Lub tsev | 245sq wb | ||
| Qhov project piav qhia | Peb tsim thiab muab ib qho kev daws teeb meem rau lub tsev no suav nrog kev cai ua huv, chav ua noj. Txhua tus ua tau raws li AU cov qauv. Mus rau: https://www.facebook.com/number1homes/ | ||
| Lub npe qhov project | BBL Chaw Nyob Project | ||
| Sijhawm tiav | Xyoo 2017 | ||
| Qhov Chaw Qhov Chaw | Coron Philippines | ||
| Lub tsev | 785 kwm | ||
| Qhov project piav qhia | Ib thiab ob lub tsev hauv pem teb rau kev pab thiab kev pabcuam pej xeem rau BBL chaw so. | ||
| Lub npe qhov project | Villa Dehaumont hauv Renuion | ||
| Sijhawm tiav | Xyoo 2017-2018 | ||
| Qhov Chaw Qhov Chaw | Renuion Island | ||
| Lub tsev | 147 sqm 3 lub tsev | ||
| Qhov project piav qhia | Heavy cua loading thiab loj ncua. Peb pre-assembled tag nrho cov ncej steel rau yooj yim installation. |
FAQ
Q. Koj yog leej twg?
A. CBC yog cov chaw muab kev pabcuam zoo tshaj plaws rau kev tsim kho vaj tsev kho mob raws li hauv Hangzhou nroog Suav.
Q: Koj tuaj yeem ua dab tsi rau kuv?
A. CBC muab ib lub tsev daws teeb meem rau tej yaam num xws li:
Steel qauv warehouse;
Steel qauv tsev apartment;
Steel qauv Rhiav;
Steel qauv kav khw;
Steel qauv tsheb-chaw;
Mining camp;
Kev tsim kho chaw pw hav zoov;
Lub tsev ib ntus;
Tus nqi qis tsev;
Lub tsev ua haujlwm;
Khoom kim heev tsev;
Resort villa;
Lub tsev neeg tawg rog;
Lub chaw kaw;
Lub Tsev me me Expandable Thawv Tsev
Q: Koj lub peev xwm muab khoom yog dab tsi?
A: Cov ntaub ntawv muaj peev xwm txhua xyoo yog raws li hauv qab no:
Thawv tsev: 7200sets
Prefab tsev; 564 000 m² os
Steel qauv: 360000 square meters.
Q: Koj tuaj yeem lav qhov project li cas thiaj tuaj yeem pom zoo los ntawm cov cai hauv zos?
A: 1) Txhua tus qauv tsim raws li koj xav tau kom ntxaws;
2) Txhua yam ntaub ntawv tuaj yeem ua tau raws li cov qauv hauv zos;
3) Kev suav cov qauv muab pub dawb los pab kom tau txais kev pom zoo;
4) Ntau tshaj 10 Xyoos kev ua haujlwm txawv teb chaws tau npaj peb zoo rau cov lus nug.
Q: Dab tsi yog txheej txheem los pib kev koom tes?
A: Qhia rau peb paub koj cov kev xav tau lossis xa cov qauv tsim;
Paub meej tias peb tus qauv tsim rau koj raws li qhov xav tau saum toj no;
Paub meej tias cov lus hais raws li peb cov qauv tsim;
Npaj cov nyiaj them poob haujlwm;
Paub meej tias lub khw kos duab thiab ua kom pom tseeb tias peb tuaj yeem ua tiav koj li cas;
Dhau qhov kev tshuaj xyuas tom qab ib ncig ntawm 30 hnub ntawm kev tsim khoom;
Npaj qhov nyiaj tshuav;
Txais thiab kawm cov lus qhia installation;
Txais cov ntaub ntawv;
Ua kom tiav lub installation raws li peb cov lus qhia thiab kev txhawb nqa engineering hauv online;
Siv peb lub tshuab BIM rau lub neej tom qab muag kev pabcuam;
Appricate koj qhov kev pom zoo lossis rov xaj dua;
Q: Koj tuaj yeem lav qhov zoo ntawm Lub Tsev Me Me Prefab li cas?
A: Kev ua tau zoo yog yav tom ntej. Kev ua tau zoo yog qhov tseem ceeb tshaj plaws.
Peb muaj tsib tus neeg QC pab pawg tshuaj xyuas kev tsim khoom txhua hnub, lawv yuav ua raws li lub khw kos duab nruj me ntsis thiab tshawb xyuas txhua feem / project thaum pib, nruab nrab thiab rau cov khoom tiav.
Peb tuaj yeem sib sau ua ke qee chav nyob hauv peb lub Hoobkas rau qee qhov tshwj xeeb customized ua haujlwm kom paub tseeb tias txhua yam zoo txaus.
