CBC Integrated Prefab Building Solution rau Cov Chaw Cov Ntaub Ntawv Niaj Hnub & AI Compute Facilities
Leveraging CBC's Steel Structure Buildings thiab Prefabricated Modular Systems



Kev nce thoob ntiaj teb hauv AI, huab xam, thiab kev ua cov ntaub ntawv ntug tau tsim qhov kev thov tsis tau muaj dua rau kev xa tawm sai.siab -qhov ceev, lub zog-nrhiav, thiab scalable data centers. Kev tsim kho ib txwm siv-feem ntau siv 18-24 lub hlis- siv tsis tau lawm. Cov neeg ua haujlwm tam sim no xav taumodular, industrialized dawsuas ua tau raws li Tier III/IV cov qauv kev ntseeg siab thaum ua kom muaj kev nthuav dav.

CBC Lub Tuam Txhab muaj ob txoj kev taug qab -:

Cov Ntaub Ntawv Tseem Ceeb: High-clearance, wide-spansteel qauv tsevrau cov chaw ua haujlwm, chav fais fab, thiab cov chaw txias

Kev them nyiaj yug & Ntug muaj nuj nqi: Ceev- xa tawmprefabricated modular tsev(Prefab Houses) rau NOC, chaw ua haujlwm, kev ruaj ntseg, roj teeb thaub qab, thiab cov chaw pabcuam

Qhov kev daws teeb meem no sib xyaw ua ke ntawm cov qauv kev ua tau zoo nrog kev ceev- rau- kev ua lag luam - xa cov ntaub ntawv ua haujlwm tag nrho hauv6–9 lub hlis, at20-30% qis dua tag nrho cov nqi nruabvs. cov qauv tsim.



Muaj nuj nqi	CBC Solution	Kev xav
Main Data Hall (IT Chaw Dawb)	Loj -span steel portal lossis truss thav duab lub tsev (ntshiab ncua mus txog 30 m, qhov siab Ntau dua lossis sib npaug li 6 m)	Ua kom haum siab -bay CRAC units, overhead cable trays, thiab kev hloov kho cov khib nyiab yav tom ntej
Hluav taws xob & UPS chav	Steel qauv + hluav taws kub - ntsuas prefab enclosures	Segregated, ruaj ntseg, nrog EMI shielding xaiv
NOC / Admin / Security	CBC Prefab Modular Tsev (3m × 6m lossis 3m × 9m units)	Factory-ua tiav nrog HVAC, teeb pom kev zoo, network cable
Edge Micro{0}}Data Centers	Tus kheej -muaj prefab modules nrog kev ua kom txias & lub zog	Deployable standalone los yog raws li lub tsev kawm ntawv extensions
Roj teeb thaub qab (Li-ion lossis VRLA)	Hluav taws kub- cov thawv ntim khoom ua ntej tiv taus nrog qhov cua thiab cov txeej txeej	Ua raws li NFPA 855 / IEC 62619





3.1 Steel Structure Tsev Nta

Thawj Ncej: Q355B los yog ASTM A572 Qib 50 kub- dov los yog ua tau - seem

Tsev / Phab ntsa Cladding:

Option A: 0.6 hli PPGL steel ntawv + 100 hli pob zeb wool rwb thaiv tsev (U-tus nqi Tsawg dua lossis sib npaug rau 0.35 W / m²K)

Kev xaiv B: Insulated Sandwich panels (PIR core, 100–150 mm, hluav taws kub B-}s1,d0 rau EN 13501)

Pem teb System: Reinforced concrete slab-ntawm-qib nrog nce nkag hauv pem teb (600–1,200 mm) kev sib xyaw ncej-kev tsim kho

Cua / Seismic: Tsim ib cov lej hauv zos (xws li ASCE 7, Eurocode 8); haum rau thaj tsam seismic mus txog Zone 3

Tiv thaiv hluav taws: Intumescent txheej los yog board tiv thaiv ntawm kab / rafters (60-120 min ntsuam xyuas)



3.2 Prefab Modular Lub Tsev Nta (rau kev txhawb nqa)

Qauv: Lub teeb-gauge steel ncej (LGSF) lossis thawv-raws li steel chassis

Phab ntsa/ru tsev: 75-100 mm PIR/pob zeb wool sandwich panels (λ=0.022 W/mK)

Integrated MEP: Ua ntej- teeb tsa cov kav dej, cov ntaub ntawv chaw nres nkoj, LED teeb pom kev zoo, cais-unit HVAC

Kev sib txuas: Plug-thiab- ua si hluav taws xob & cov ntaub ntawv cuam tshuam ntawm cov modules

Durability: IP54- ntsuas cov ntaub ntawv; corrosion-resistant finishes (C4 ib puag ncig ua raws)



CBC's hybrid tov ua ke nrog cov kev cai tseem ceeb hauv kev lag luam:

Txuj	CBC Txoj Kev Ua Raws Cai
TIA-942-B / ANSI / BICSI 002	Cov txheej txheem cabling txoj kev ua ntej -tsim; kev sib cais ntawm lub zog / cov ntaub ntawv zones
NFPA 75/76	Hluav taws-rated compartmentalization; nrhiav pom cov pa luam yeeb ntxhib-ins
ASHRAE TC 9.9	Lub qab nthab siab (Ntau dua lossis sib npaug li 6 m) ua kom lub tshav kub / txias thiab cua ntws tau zoo
ISO / IEC 27001 Kev Tswj Xyuas Zoo	Kev ruaj ntseg module tsim nrog kev nkag mus tswj kev sib koom ua ke cov ntsiab lus
LEED / Energy Star	Reflective roofing, high rwb thaiv tsev, thiab hnub ci- npaj ru tsev tsim txo PUE hauv paus

Nco tseg: Thaum CBC muab lub plhaub thiab cov tub ntxhais, cov tshuab tseem ceeb (UPS, generators, chillers, racks) yog kev koom ua ke los ntawm cov neeg koom tes tshwj xeeb-tab sis CBC tus qauv tsim suav nrog txhua qhov tsim nyog tshem tawm, lub peev xwm thauj khoom (Ntau dua lossis sib npaug rau 12 kN / m² pem teb load), thiab lub tes tsho siv hluav taws xob.





✅ Ceev - rau - Kev Lag Luam (6-9 Lub Hlis vs . 18+ Lub Hlis)

Parallel Workflow: Lub hauv paus ua haujlwm tau ua haujlwm thaum steel thav duab thiab prefab modules raug tsim tawm ntawm -site

Hoobkas Precision: 90% ntawm MEP ntxhib-ins ua tiav hauv Hoobkas → tsawg heev ntawm- qhov chaw rov ua haujlwm

Rapid Erection: Main steel qauv tsim nyob rau hauv 2-3 lub lis piam; prefab kev them nyiaj yug vaj tse ntsia nyob rau hauv hnub



✅ Nqis peev (20-30% txo)

Nqi Element	Kev Tsim Kho	CBC Hybrid Solution	Txuag
Tus Qauv Ncej	$180–220/m²	$120–150/m²	~25%
Lub hnab ntawv (phab ntsa / ru tsev)	$90–110/m²	$70–85/m²	~20%
Labor (Ntawm -site)	High ( txawj welders, electricians)	Txo los ntawm 60%	Qhov tseem ceeb
Teem caij nplua Risk	Siab	Yam tsawg kawg nkaus (lub sijhawm ua haujlwm ruaj khov)	Indirect kev txuag nyiaj

Piv txwv: A 2,000 m² data hall + 500 m² txhawb cov chaw

Pa CAPEX: ~ $ 4.5M

CBC Hybrid CAPEX:~$3.2M(nrog rau kev thauj mus los, kev teeb tsa, chaw ua haujlwm yooj yim)



✅ Scalability & Phased Deployment

Pib nrog ib 1,000 m² nrog; ntxiv cov bays uas nyob ib sab siv tib kab kab sib chaws

Prefab NOC/admin tuaj yeem hloov chaw lossis rov ua dua tshiab - nthuav dav



✅Sustainability Benefits

Hlau: >90% recycled cov ntsiab lus; 100% recyclable thaum kawg - ntawm - lub neej

Txo cov pov tseg: Lub Hoobkas ntau lawm txiav cov khoom pov tseg los ntawm ~ 70%

Zog Efficiency: High rwb thaiv tsev + reflective nto qis txias load →PUE txo ntawm 0.05–0.10ua tiav tau vs. tsis yog- cov vaj tse hlau insulated



Kev tsim khoom: CBC factories hauv Hangzhou, Suav teb (ISO 9001/14001 tau ntawv pov thawj)

Export Ntim: Steel Cheebtsam bundled; prefab modules tiaj tus- ntim lossis ntim khoom (16 units / 40HC)

Logistics: Qhov rooj-rau- chaw xa khoom thoob ntiaj teb; koom tes nrog DHL, COSCO, thiab cov tuam txhab EPC hauv zos

Kev them nyiaj yug Installation: CBC muab pab neeg saib xyuas + kev sib koom tes digital BIM





CBC's integratedSteel Structure + Prefab Modulardlaws xa ayav tom ntej -npaj, code- ua raws, thiab kev lag luam zoo duatxoj hauv kev rau niaj hnub cov ntaub ntawv chaw thiab AI suav cov chaw tsim kho. Los ntawm decoupling lub siab - cov ntaub ntawv kev ua tau zoo (yuav tsum tau muaj zog, qhov siab, thiab yooj) los ntawm kev siv tau sai sai, CBC ua rau cov neeg ua haujlwm:

Siv sai duateb rau AI-tsav muaj peev xwm xav tau

Txo CAPEX thiab kev pheej hmoo ua haujlwmlos ntawm kev tsim kho industrialized

Ua kom muaj scalability thiab sustainabilitytsis cuam tshuam kev ntseeg

Nyob rau hauv ib lub sijhawm uas "lub sijhawm-rau-ntsis" yog qhov tseem ceeb raws li kev siv hluav taws xob, CBC tus qauv hybrid sawv cev rau kev hloov pauv tom ntej hauv kev xa khoom digital-industrialized, ntse, thiab instantly deployable.
