CBC Steel Structure Warehouse Tsim Rau Cebu, Philippines (Irregular Shape)

CBC Steel Structure Warehouse Design for Cebu, Philippines (Irregular Shape) - Q&A nrog cov npe khoom thiab kev soj ntsuam kev lag luam

Qhov no yog ib qho kev tsim ntawm cov khoom siv hlau tsis sib xws uas siv CBC steel qauv tsev rau Cebu, Philippines cov neeg siv khoom. Nws suav nrog kev txheeb xyuas cov qauv tsim, cov ncauj lus kom ntxaws cov ntaub ntawv thiab kev siv rau ob hom cladding cov ntaub ntawv, thiab kev soj ntsuam ntawm qhov siv tau ntawm tus qauv tsim hauv ntau lub lag luam Philippines.

1. General Design Overview



A1: Lub tsev khaws khoom siv CBC steel qauv tsim lub tsev thiab nta lub dav hlau tsis xwm yeem trapezoidal. Nws cov ntsiab lus tseem ceeb yog raws li nram no: Sab qab teb dav yog 27.5 meters, sab qaum teb dav yog 32.6 meters, thiab tag nrho ntev yog 34.5 meters. Lub steel kem qhov sib nrug yog 8.4m + 8.4m + 8.4m + 9.2m=34.5m (tag nrho ntev). A 4-meter-siab mezzanine yog teem rau sab qab teb tshaj plaws 8.4m raws li chaw ua haujlwm. Lub qhov siab ntawm lub warehouse yog 8 meters, lub ridge yog nruab nrog cua louvers, thiab lub ridge qhov siab yog 12.8 meters.





A2: Lub CBC (Customized Building Company) steel qauv lub tsev yog lub teeb yuag, siab - lub zog, thiab cov qauv siv tau zoo uas ua ke nrog cov kab hlau, cov kab sib xyaw ua ke, thiab cov khoom siv sib sib zog nqus. Nws yog tus cwj pwm los ntawm kev muaj zog load-cov kabmob muaj peev xwm, kev ua haujlwm zoo seismic, kev tsim kho ceev ceev, thiab kev siv qhov chaw siab. Nws raug xaiv rau qhov tsim no feem ntau yog vim li cas peb:

Ua ntej, nws tuaj yeem hloov kho kom zoo rau lub dav hlau trapezoidal ntawm lub tsev khaws khoom (sab qab teb dav 27.5m, sab qaum teb dav 32.6m) los ntawm kev hloov kho qhov sib txuas ntawm cov kab hlau thiab kab;

Qhov thib ob, nws tuaj yeem ua tau raws li cov khoom thauj -cov kabmob uas yuav tsum tau muaj ntawm 4-meter-siab mezzanine chaw ua haujlwm nyob rau sab qab teb;

Thib peb, nws cov yam ntxwv ntawm lub teeb yuag tuaj yeem txo cov nqi hauv paus, uas tsim nyog rau kev tsim kho hauv Cebu, Philippines.

Tsis tas li ntawd, CBC system muaj kev sib raug zoo nrog ntau yam ntaub ntawv cladding (xim steel ib daim ntawv thiab 50mm EPS sandwich vaj huam sib luag), uas tuaj yeem ua tau raws li qhov sib txawv ntawm cov neeg siv khoom.

2. Kev Ntsuam Xyuas Tus Qauv Tsim Qauv



A3: Rau lub dav hlau tsis xwm yeem trapezoidal (sab qab teb dav 27.5m, sab qaum teb dav 32.6m), cov kev ntsuas hauv qab no tau txais los ntawm cov qauv tsim los xyuas kom muaj kev ruaj ntseg:

Ua ntej, cov kab hlau yog teem raws li qhov ntev ntawm kev taw qhia (34.5m) raws li qhov sib nrug ntawm 8.4m + 8.4m + 8.4m + 9.2m, thiab cov ko taw ko taw tau tsim raws li kev txhawb nqa ruaj khov los txhim kho qhov kev nruj ntawm cov qauv.

Thib ob, cov kab teeb -Kem txuas nodes txais kev sib txuas tsis tu ncua (CBC system's core node design), uas tuaj yeem hloov kho lub sijhawm khoov thiab lub zog shear, thiab sib koom ua ke qhov deformation ntawm lub dav hlau tsis xwm yeem.

Thib peb, kab rov tav bracings yog teem nyob rau hauv longitudinal thiab transverse cov lus qhia ntawm lub warehouse: longitudinal bracings yog teem nyob rau hauv ob qho tib si kawg ntawm lub warehouse (sab qab teb thiab sab qaum teb sab) thiab nruab nrab ntawm cov steel kab los tiv thaiv longitudinal cua load thiab seismic quab yuam; transverse bracings yog teem rau hauv txhua qhov kev ncua los daws qhov teeb meem ntawm kev ntxhov siab tsis sib xws los ntawm lub dav hlau trapezoidal.

Plaub, lub ru tsev truss yog tsim raws li ib tug sloped truss (ridge qhov siab 12.8m, warehouse clear height 8m), thiab lub truss spacing yog raws li nyob rau hauv lub steel kem spacing, uas tsis tsuas yog xyuas kom meej lub ru tsev tab sis kuj sib npaug qhov kev ntxhov siab ntawm lub dav hlau tsis xwm yeem.





A4: Lub chaw ua haujlwm mezzanine yog teem rau yav qab teb tshaj plaws 8.4m ncua, nrog qhov siab ntawm 4 meters (los ntawm hauv av mus rau hauv pem teb mezzanine). Cov qauv tsim ntawm mezzanine yog kev koom ua ke nrog CBC steel qauv system:

Ua ntej, cov kab hlau hauv qhov kev ncua no tau nce mus txog 4 meters los txhawb lub mezzanine beam, thiab cov seem seem yog nce me ntsis (piv nrog rau lwm cov spans) kom dais ntxiv load ntawm mezzanine.

Qhov thib ob, mezzanine beam txais cov kab teeb ci sib xyaw (CBC customized beams), uas yog tsim los ntawm cov kab hlau steel thiab pob zeb ua vaj tse. Cov nqaj hlau txuas nrog steel kem los ntawm cov kab nrib pleb, thiab cov pob zeb ua pob zeb yog cam khwb cia rau ntawm cov nqaj hlau los txhim kho cov kabmob muaj peev xwm thiab nruj ntawm mezzanine.

Thib peb, lub mezzanine pem teb yog paving nrog pob zeb slabs (thickness 120mm), uas tuaj yeem ua tau raws li qhov yuav tsum tau siv hauv chaw ua haujlwm (load-cov kabmob muaj peev xwm Ntau dua lossis sib npaug li 2.5kN / m²).

Plaub, lub railing yog teem nyob ib ncig ntawm lub mezzanine (qhov siab 1.1m), thiab railing yog ua los ntawm steel kav, uas yog txuas nrog lub mezzanine beam kom muaj kev ruaj ntseg.

Tsis tas li ntawd, lub mezzanine raug cais tawm ntawm thaj chaw warehouse los ntawm lub teeb steel partitions (raws li cov khoom siv cladding xaiv los ntawm cov neeg siv khoom), uas ua kom muaj kev ywj pheej ntawm lub chaw ua haujlwm thiab tsis cuam tshuam rau kev siv lub tsev rau khoom.



A5: Cov cua louvers yog teem rau ntawm lub ridge ntawm lub warehouse (ridge qhov siab 12.8m), nrog ib tug ntev raws li tag nrho ntev ntawm lub warehouse (34.5m) thiab ib tug dav ntawm 1.2m. Lub luag haujlwm tseem ceeb ntawm cov cua louvers yog qhov cua thiab cua sov dissipation ntawm lub warehouse. Cov qauv tsim ntawm cov cua louvers yog raws li nram no:

Ua ntej, lub thav duab ntawm cov cua louvers yog ua los ntawm steel profiles (lub kaum sab xis steel thiab channel steel), uas txuas nrog lub ru tsev truss los ntawm vuam thiab bolts kom ruaj khov kev twb kev txuas.

Qhov thib ob, cov louvers yog ua los ntawm aluminium alloy (corrosion-}resistant, haum rau cov huab cua hauv hiav txwv hauv Cebu), thiab cov louvers tau teeb tsa rau ntawm cov ncej hlau nrog pob khawm kom yooj yim qhib thiab kaw.

Thib peb, cov cua load tiv thaiv tsim ntawm cov cua louvers tau ntxiv dag zog: xav txog qhov nquag typhoons nyob rau hauv Philippines, cua load ntawm cov cua louvers yog xam raws li lub zos cua load txheem (Philippine National Building Code, PNBC), thiab cov steel ncej yog optimized los xyuas kom meej tias cov cua louvers tuaj yeem tiv taus cua siab tshaj plaws hauv Cebu (txog 25km).

Thib plaub, kev ntsuas dej tsis zoo yog coj los ntawm kev sib txuas ntawm cov cua louvers thiab lub ru tsev: cov dej tsis sib haum yog ntim rau ntawm cov hlau ntawm cov cua louvers thiab lub ru tsev cladding, thiab cov ntaub thaiv dej tsis muaj dej ntxiv los tiv thaiv cov dej los nag.





A6: Ua ke nrog qhov chaw ntawm Cebu, Philippines (kev nyab xeeb maritime, nquag typhoons, nruab nrab seismic kev ua si) thiab kev siv lub warehouse, cov nram qab no load xam xam nyob rau hauv cov qauv tsim:

1. Kev thauj khoom tuag: suav nrog qhov hnyav ntawm cov khoom siv hlau (kab, kab teeb, trusses), cov ntaub ntawv cladding, mezzanine pem teb, cua louvers, thiab lwm yam khoom ruaj khov;

2. Kev thauj khoom nyob: suav nrog cov khoom nyob hauv pem teb (Ntau dua lossis sib npaug ntawm 5kN / m², haum rau cov khoom siv dav dav), cov khoom siv nyob ntawm lub chaw ua haujlwm mezzanine (Ntau dua lossis sib npaug rau 2.5kN / m²), thiab cov khoom nyob ntawm lub ru tsev (Ntau dua lossis sib npaug ntawm 0.5kN / m²);

3. Cua thauj khoom: raws li PNBC, qhov yooj yim cua siab hauv Cebu yog 0.7kPa, thiab cua load yog xam raws li qhov siab ntawm cov qauv (ridge qhov siab 12.8m, warehouse siab 8m) thiab lub dav hlau tsis xwm yeem, thiab cua{4}} tiv thaiv kev ntsuas (bracings, rigid nodes) raug coj los xyuas kom muaj kev ruaj ntseg;

4. Seismic load: Cebu yog nyob rau hauv ib tug nruab nrab seismic cheeb tsam, lub seismic siv yog tsim raws li 7 degrees, thiab CBC steel qauv system qhov zoo ductility thiab seismic kev ua tau zoo yog siv los txo cov kev cuam tshuam ntawm av qeeg;

5. Lwm yam kev thauj khoom: suav nrog cov daus daus (tsis pom zoo hauv Cebu, Philippines) thiab cov cua thauj khoom ntawm cov cua louvers.





A7: Ua ke nrog kev suav cov load thiab cov qauv tsim, cov qauv tsim ntawm cov hlau tseem ceeb yog raws li hauv qab no:

1. Cov kab hlau: H- cov kab hlau zoo li tau txais yuav, thiab cov seem loj tau hloov kho raws li kev ncua thiab thauj khoom: cov kab ke hauv qhov mezzanine ncua (sab qab teb 8.4m) yog H350 × 175 × 7 × 11 (kom dais lub mezzanine load), thiab sab seem hauv lwm qhov spans yog H300 × 110 × kem qhov siab yog 8m (warehouse qhov siab), thiab kem taw yog tsau kev txhawb nqa.

2. Hlau kab: CBC customized kab teeb raug saws, thiab seem loj yog H300 × 150 × 6 × 10 ( ncua 8.4m) thiab H350 × 175 × 7 × 11 ( ncua 9.2m); cov kab teeb yog txuas nrog cov kab los ntawm cov kab nrib pleb, thiab cov kab teeb mezzanine txuas nrog cov kab thiab cov kab hluav taws xob warehouse beams los tsim ib qho kev ruaj khov.

3. Roof trusses: Daim duab peb sab steel trusses yog saws, nrog ib tug span raws li cov steel kem sib nrug (8.4m thiab 9.2m), thiab truss qhov siab yog 2.8m (los ntawm sab saum toj ntawm kem mus rau lub ridge); Cov tswv cuab truss yog ua los ntawm lub kaum sab xis steel (L140 × 90 × 10, L125 × 80 × 8) thiab channel steel (C160 × 63 × 6), thiab cov truss nodes txuas nrog vuam los xyuas kom meej cov load{13}}cov kabmob muaj peev xwm ntawm lub ru tsev.

3. Cov ntawv teev cov khoom siv thiab kev siv (ob hom khoom siv cladding)



A8: Cov xim hlau ib daim ntawv (thickness 0.6mm, xim: dawb rau lub ru tsev, grey rau phab ntsa) yog siv los ua ru tsev thiab phab ntsa cladding cov ntaub ntawv, thiab cov ncauj lus kom ntxaws cov ntaub ntawv thiab kev noj yog qhia nyob rau hauv cov lus nram qab no (tsis suav cov steel qauv tseem ceeb, tsuas yog cladding cov ntaub ntawv thiab accessories):

Khoom npe	Specification	Daim Ntawv Thov Txoj Haujlwm	Kev siv nyiaj txiag hauv paus	Kev siv tag nrho	Chav tsev
Xim Hlau Ib Daim Ntawv	0.6mm, dav 1000mm, yoj qhov siab 35mm	Ru tsev (tsis suav nrog cua louvers)	ru tsev cheeb tsam=trapezoidal cheeb tsam=(sab qab teb dav + sab qaum teb dav) × tag nrho ntev / 2=(27.5 + 32.6) × 34.5 / 2 ≈ 1036.95 ㎡; ntxiv 5% poob rau kev txiav thiab kev teeb tsa	1088.80	㎡
Xim Hlau Ib Daim Ntawv	0.6mm, dav 1000mm, yoj qhov siab 35mm	Warehouse Wall (tsis suav nrog phab ntsa mezzanine)	Phab ntsa=( cheeb tsam sab qab teb phab ntsa + cheeb tsam sab qaum teb phab ntsa + cheeb tsam phab ntsa sab hnub tuaj + thaj tsam phab ntsa sab hnub poob) - qhov rooj thiab qhov rais; sab qab teb phab ntsa: 27.5m × 8m=220 ㎡; sab qaum teb phab ntsa: 32.6m × 8m=260.8 ㎡; phab ntsa sab hnub tuaj / sab hnub poob: nruab nrab qhov dav ({11}}) / 2 × 8m=240.4 ㎡ txhua, tag nrho 480.8 ㎡; qhov rooj / qhov rai: 40 ㎡ (xav tias); tag nrho phab ntsa: 220+260.8+480.8-40=921.6 ㎡; ntxiv 5% poob	967.68	㎡
Xim Hlau Ib Daim Ntawv	0.6mm, dav 1000mm, yoj qhov siab 25mm	Mezzanine Office Phab ntsa	Mezzanine phab ntsa cheeb tsam: 8.4m × 4m × 2 (sab hnub tuaj / sab hnub poob) + 27.5m × 4m (sab qab teb) - 15 ㎡ (chaw ua haujlwm qhov rooj / qhov rai, assumed)=67.2 + 110 - 15=162.2 ㎡; ntxiv 5% poob	170.31	㎡
Xim Hlau Ib Daim Ntawv	0.6mm, dav 1000mm, yoj qhov siab 25mm	Mezzanine Office Qab nthab	Qab nthab cheeb tsam=8.4m × 27.5m=231 ㎡; ntxiv 5% poob	242.55	㎡
Hlau Purlin	C140×60×2.5	Lub Tsev Purlin	Purlin nrug 1.2m; tag nrho ntev ntawm lub ru tsev purlins=(tus naj npawb ntawm purlins × ncua ntev); tus naj npawb ntawm purlins=tag nrho lub ru tsev ntev / purlin spacing + 1=34.5 / 1.2 + 1 ≈ 30; ncua ntev nruab nrab (27.5+32.6)/2 ≈ 30.05m; tag nrho ntev: 30 × 30.05=901.5m; ntxiv 3% poob	928.55	m
Hlau Purlin	C120×50×2.5	Phab ntsa Purlin	Purlin nrug 1.5m; tag nrho ntev ntawm phab ntsa purlins=(sab qab teb phab ntsa + sab qaum teb phab ntsa + sab hnub tuaj phab ntsa + sab hnub poob phab ntsa) × (qhov siab / purlin spacing + 1); Sab qab teb phab ntsa: 27.5 × (8/1.5 + 1) ​​≈ 27.5 × 6.33≈174.08m; Sab qaum teb phab ntsa: 32.6 × 6.33≈206.36m; Sab hnub tuaj / sab hnub poob: 34.5 × 6.33≈ 218.39m txhua qhov, tag nrho 436.78m; tag nrho ntev: 174.08+206.36+436.78≈817.22m; ntxiv 3% poob	841.74	m
Waterproof Sealant	Tsis siv neeg silicone, dub	ru tsev, phab ntsa, cua louvers pob qij txha	Raws li kev sib koom ua ke ntev: tag nrho qhov sib koom ua ke ntev ≈ 1200m; noj 0.1kg / m	120.00	kg
Tus kheej -tapping Ntsia Hlau	M5 × 25, galvanized	Kho xim hlau ntawv rau purlin	Kev siv 8 daim / ㎡; tag nrho cladding cheeb tsam ≈ 1088.8+967.68+170.31+242.55≈2469.34 ㎡; Tag nrho cov khoom: 2469.34 × 8≈19754.72; ntxiv 5% poob	20742.46	ib daim
Aluminium Alloy Louver	Thickness 1.0mm, dav 100mm	Ridge Cua Louvers	Cua louvers cheeb tsam=34.5m × 1.2m=41.4 ㎡; ntxiv 5% poob	43.47	㎡
Hlau Ncej rau Cua Louvers	Lub kaum sab xis hlau L50 × 50 × 5, Channel Steel C100 × 50 × 5	Ridge Cua Louvers Ncej	Ncej ntev=34.5m (ntev) × 2 + 1.2m (transverse) × 30 (spacing 1.2m)=69 + 36=105m; ntxiv 3% poob	108.15	m
Qhov rooj thiab qhov rai	Hlau Qhov Rooj (3m × 2.5m), Aluminium Alloy Qhov rai (1.5m × 1.2m)	Warehouse thiab Office	Warehouse: 2 steel qhov rooj, 4 aluminium alloy qhov rais; Chaw Ua Haujlwm: 1 lub qhov rooj steel, 3 aluminium alloy qhov rais	Qhov rooj: 3, Qhov rai: 7	ib daim



A9: 50mm EPS sandwich panels (thickness 50mm, xim: dawb rau lub ru tsev, grey rau phab ntsa; nto xim steel ntawv thickness 0.5mm, core material ntom 18kg/m³) yog siv los ua ru tsev thiab phab ntsa cladding cov ntaub ntawv, thiab cov ncauj lus kom ntxaws cov ntaub ntawv thiab noj yog qhia nyob rau hauv cov lus hauv qab no (tsis suav nrog steel qauv thiab cov khoom tseem ceeb), tsuas yog cladding cov ntaub ntawv.

Khoom npe	Specification	Daim Ntawv Thov Txoj Haujlwm	Kev siv nyiaj txiag hauv paus	Kev siv tag nrho	Chav tsev
50mm EPS Sandwich Vaj Huam Sib Luag	Tag nrho thickness 50mm, nto xim hlau 0.5mm, core ceev 18kg / m³, dav 1000mm	Ru tsev (tsis suav nrog cua louvers)	Ib yam li xim hlau ib daim ntawv: ru tsev cheeb tsam ≈ 1036.95 ㎡; ntxiv 5% poob rau kev txiav thiab kev teeb tsa	1088.80	㎡
50mm EPS Sandwich Vaj Huam Sib Luag	Tag nrho thickness 50mm, nto xim hlau 0.5mm, core ceev 18kg / m³, dav 1000mm	Warehouse Wall (tsis suav nrog phab ntsa mezzanine)	Ib yam li xim hlau ib daim ntawv: phab ntsa cheeb tsam ≈ 921.6 ㎡; ntxiv 5% poob	967.68	㎡
50mm EPS Sandwich Vaj Huam Sib Luag	Tag nrho thickness 50mm, nto xim hlau 0.5mm, core ceev 18kg / m³, dav 1000mm	Mezzanine Office Phab ntsa	Ib yam li xim hlau ib daim ntawv: mezzanine phab ntsa ≈ 162.2 ㎡; ntxiv 5% poob	170.31	㎡
50mm EPS Sandwich Vaj Huam Sib Luag	Tag nrho thickness 50mm, nto xim hlau 0.5mm, core ceev 18kg / m³, dav 1000mm	Mezzanine Office Qab nthab	Ib yam li xim hlau ib daim ntawv: qab nthab cheeb tsam=231 ㎡; ntxiv 5% poob	242.55	㎡
Hlau Purlin	C160×70×3.0	Lub Tsev Purlin	EPS sandwich vaj huam sib luag hnyav dua li xim hlau ib daim ntawv; purlin sib nrug 1.0m; tus naj npawb ntawm purlins=34.5 / 1.0 + 1=35.5 ≈ 36; ncua ntev nruab nrab 30.05m; tag nrho ntev: 36 × 30.05=1081.8m; ntxiv 3% poob	1114.25	m
Hlau Purlin	C140×60×3.0	Phab ntsa Purlin	Purlin nrug 1.2m; tag nrho ntev ntawm phab ntsa purlins=(sab qab teb phab ntsa + sab qaum teb phab ntsa + sab hnub tuaj phab ntsa + sab hnub poob phab ntsa) × (qhov siab / purlin spacing + 1); Sab qab teb phab ntsa: 27.5 × (8/1.2 + 1) ​​≈ 174.08m; Sab qaum teb phab ntsa: 32.6 × 6.33≈206.36m; Sab hnub tuaj / sab hnub poob: 34.5 × 6.33≈ 218.39m txhua qhov, tag nrho 436.78m; tag nrho ntev: 817.22m; ntxiv 3% poob	841.74	m
Waterproof Sealant	Tsis siv neeg silicone, dub	ru tsev, phab ntsa, cua louvers pob qij txha	Ib yam li xim hlau ib daim ntawv: tag nrho qhov sib koom ua ke ntev ≈ 1200m; noj 0.15kg / m (EPS vaj huam sib luag pob qij txha xav tau ntau sealant)	180.00	kg
Tus kheej -tapping Ntsia Hlau	M5 × 35, galvanized (nrog gasket tsis muaj dej)	Txhim kho EPS sandwich vaj huam sib luag rau purlin	Kev siv 10 daim / ㎡; tag nrho cladding cheeb tsam ≈ 2469.34 ㎡; Tag nrho cov khoom: 2469.34 × 10≈24693.4; ntxiv 5% poob	25928.07	ib daim
Aluminium Alloy Louver	Thickness 1.0mm, dav 100mm	Ridge Cua Louvers	Ib yam li xim hlau ib daim ntawv: cua louvers cheeb tsam ≈ 41.4 ㎡; ntxiv 5% poob	43.47	㎡
Hlau Ncej rau Cua Louvers	Lub kaum sab xis hlau L50 × 50 × 5, Channel Steel C100 × 50 × 5	Ridge Cua Louvers Ncej	Ib yam li xim hlau ib daim ntawv: ncej ntev ≈ 105m; ntxiv 3% poob	108.15	m
Qhov rooj thiab qhov rai	Hlau Qhov Rooj (3m × 2.5m), Aluminium Alloy Qhov rai (1.5m × 1.2m)	Warehouse thiab Office	Ib yam li xim hlau ib daim ntawv: Warehouse: 2 steel qhov rooj, 4 aluminium alloy qhov rais; Chaw Ua Haujlwm: 1 lub qhov rooj steel, 3 aluminium alloy qhov rais	Qhov rooj: 3, Qhov rai: 7	ib daim
EPS Vaj Huam Sib Luag Connector	Aluminium alloy, ntev 1000mm	EPS Sandwich vaj huam sib luag pob qij txha	Kev siv 1m / ㎡; tag nrho cladding cheeb tsam ≈ 2469.34 ㎡; ntxiv 5% poob	2592.81	m

4. Philippine Kev Ua Lag Luam Sib txawv thiab tsim kev siv tau



A10: Qhov sib txawv tseem ceeb ntawm Manila, Davao, thiab Cebu nyob rau hauv steel qauv warehouse tsim yog tshwm sim nyob rau hauv plaub yam:

1. Kev nyab xeeb thiab ib puag ncig: Manila nyob rau sab qaum teb ntawm Philippines, nrog cov cua daj cua dub ntau zaus (cov cua kub siab 0.8kPa) thiab kub thiab av noo; Cebu yog nyob rau hauv nruab nrab thaj tsam Visayas, nrog rau kev nyab xeeb marine, nruab nrab typhoon siv (pib cua siab 0.7kPa), thiab kuj sib npaug kub thiab av noo; Davao nyob rau sab qab teb ntawm Philippines, nrog ob peb lub typhoons (qhov cua cua siab 0.6kPa), kub siab, thiab dej nag.

2. Kev tsim kho tshwj xeeb thiab cov kev cai: Manila, raws li lub peev, muaj cov cai nruj me ntsis hauv lub tsev (tsim siv PNBC 2015), cov kev xav tau ntau dua rau kev nyab xeeb ntawm cov qauv (tshwj xeeb yog cua tsis kam thiab seismic resistance), thiab nruj dua kev tiv thaiv ib puag ncig rau cov ntaub ntawv cladding; Cebu thiab Davao muaj qhov tshwj xeeb xoob, tab sis Cebu, raws li lub nroog chaw nres nkoj loj, muaj kev xav tau ntau dua rau cov khoom siv ruaj khov (corrosion resistance) vim huab cua hauv hiav txwv; Davao muaj qhov yuav tsum tau qis dua rau cov cua tsis kam, tiam sis cov kev xav tau siab dua rau kev rwb thaiv tsev kub ntawm cov tsev khaws khoom vim qhov kub thiab txias.

3. Kev xav tau ntawm kev lag luam thiab daim ntawv thov scenarios: Manila muaj qhov xav tau ntau rau siab - cov chaw khaws khoom lag luam (xws li chaw xa khoom, chaw cia txias), thiab lub tsev khaws khoom loj feem ntau, yuav tsum tau siv qhov chaw siab thiab cov chaw txhawb nqa; Cebu's warehouse xav tau tsuas yog rau qhov chaw nres nkoj - ntsig txog kev cia khoom (xws li cov khoom thauj khoom, cov khoom siv raw khoom), nrog rau cov nplai me me thiab cov kev xav tau siab rau cov qauv kev hloov pauv (cov duab tsis xwm yeem yog ib txwm muaj); Davao lub warehouse xav tau tsuas yog rau kev ua liaj ua teb thiab mining khoom cia, nrog me me mus rau nruab nrab nplai thiab tseem ceeb rau kev tswj tus nqi.

4. Tus nqi tsim kho thiab cov khoom siv: Manila muaj cov nqi tsim kho siab (kev ua haujlwm, khoom siv, av), thiab kev muab cov khoom zoo - steel thiab cladding cov ntaub ntawv yog txaus; Cebu tus nqi tsim kho yog nruab nrab, thiab kev muab cov khoom siv hlau thiab cov ntaub ntawv cladding txaus, tab sis cov ntaub ntawv siab - kawg yuav tsum tau los ntawm Manila; Davao tus nqi tsim kho yog qhov qis tshaj plaws, tab sis cov khoom siv yog txwv, thiab cov khoom siv feem ntau yuav tsum tau thauj los ntawm lwm thaj chaw, ua rau muaj kev tsim kho ntev dua.



A11: Lub tsev tsim khoom tsis zoo steel qauv siv tau zoo heev rau Cebu, thiab nws qhov kev siv tau hauv Manila thiab Davao yog raws li hauv qab no:

1. Kev siv tau hauv Cebu: Cov qauv tsim tau ua tiav raws li Cebu cov yam ntxwv kev lag luam thiab kev tsim kho:

Ua ntej, CBC steel qauv system qhov hloov pauv ntawm tus qauv tsim tuaj yeem hloov kho kom zoo rau lub dav hlau trapezoidal ntawm lub tsev khaws khoom, uas yog raws li Cebu qhov chaw nres nkoj - ntsig txog warehouse xav tau (cov duab tsis sib xws yog tshwm sim vim muaj kev txwv hauv av);

Thib ob,cov cua load tsim (0.7kPa) yog raws li Cebu lub hauv paus cua siab, thiab cua - tiv thaiv kev ntsuas (bracings, rigid nodes, cua louvers) tuaj yeem tiv taus typhoons hauv zos;

Peb,ob qho kev xaiv cladding cov ntaub ntawv (xim steel ib daim ntawv thiab 50 hli EPS sandwich vaj huam sib luag) tuaj yeem ua tau raws li cov nqi sib txawv thiab cov kev xav tau ntawm Cebu cov neeg siv khoom: xim hlau ib daim ntawv yog tsim rau cov neeg siv khoom nrog cov nqi tswj nruj, thiab 50 hli EPS sandwich vaj huam sib luag yog tsim rau cov neeg siv khoom uas xav tau kev rwb thaiv tsev kub (Cebu kub);

Plaub,lub mezzanine chaw ua hauj lwm tsim integrates chaw ua hauj lwm thiab cia zog, txhim kho qhov chaw siv, uas yog haum rau me thiab nruab nrab- warehouses loj nyob rau hauv Cebu;

Thib tsib, CBC system txoj kev tsim kho ceev ceev tuaj yeem hloov mus rau Cebu qhov chaw nres nkoj kev tsim kho raws sijhawm.



2. Kev siv tau hauv Manila: Tus qauv tsim yog siv tau rau Manila, tab sis yuav tsum tau ua kom zoo dua:

Ua ntej,cov cua load tsim yuav tsum tau nce mus rau 0.8kPa kom tau raws li Manila cov kev cai typhoon tsis kam;

Thib ob,seem steel tivthaiv yuav tsum tau nce me ntsis kom tau raws li Manila cov qauv kev nyab xeeb siab dua;

Peb,cov ntaub ntawv cladding yuav tsum tau ua kom tau raws li Manila qhov kev tiv thaiv ib puag ncig (xws li siv cov khoom siv EPS tus phooj ywg ib puag ncig);

Plaub,lub chaw ua haujlwm mezzanine tuaj yeem nthuav dav raws li Manila lub chaw logistics xav tau (nce thaj tsam mezzanine). Tom qab kev ua kom zoo, nws tuaj yeem siv tau rau Manila qhov nruab nrab -cov chaw xa khoom loj.



3. Kev siv hauv Davao: Tus qauv tsim muaj feem xyuam rau Davao, thiab tus nqi tuaj yeem txo:

Ua ntej,Davao muaj ob peb typhoons, yog li cua - tiv thaiv kev ntsuas tau yooj yim (txo cov bracings), thiab cov hlau tivthaiv yuav raug txo kom txo nqi;

Thib ob,Davao qhov kub thiab txias yuav tsum muaj kev rwb thaiv tsev zoo dua, yog li 50mm EPS sandwich vaj huam sib luag yog qhov tsim nyog dua li cov khoom siv cladding;

Peb,Davao lub warehouse xav tau tsuas yog rau kev ua liaj ua teb thiab mining khoom cia, yog li lub mezzanine chaw ua hauj lwm yuav ua tau yooj yim (txo lub mezzanine cheeb tsam) kom txuag tau nqi;

Plaub,CBC system cov yam ntxwv ntawm lub teeb yuag tuaj yeem txo cov nqi hauv paus, uas tsim nyog rau Davao txoj kev tsim kho (tsuas yog lub hauv paus tsim muaj peev xwm). Tom qab kev txhim kho tus nqi, nws yog qhov tsim nyog rau Davao cov khoom me me thiab nruab nrab - cov chaw ua liaj ua teb thiab mining warehouses.



A12: Piv nrog cov qauv steel qauv warehouses nyob rau hauv Philippine lag luam, lub tsev warehouse tsim muaj plaub qhov zoo:

1. Strong adaptability rau irregular planes:CBC steel qauv system qhov hloov pauv ntawm tus qauv tsim tuaj yeem daws tau qhov teeb meem ntawm qhov tsis sib xws ntawm kev ntxhov siab nyob rau hauv qhov tsis sib xws ntawm cov khoom lag luam trapezoidal, uas yog qhov tsim nyog rau kev ua lag luam Philippines (qhov kev txwv feem ntau ua rau cov khoom tsis sib xws) dua li cov qauv steel qauv warehouses (tsis zoo adaptability rau cov dav hlau tsis xwm yeem).

2. Ntsuas tus nqi thiab kev ua haujlwm zoo: Ob qhov kev xaiv cladding cov ntaub ntawv tuaj yeem ua tau raws li cov neeg siv khoom xav tau, thiab CBC system cov yam ntxwv sib sib zog nqus txo lub hauv paus thiab cov nqi khoom, uas yog ntau dua nyob rau hauv txoj kab nrog Philippine kev lag luam nrhiav tus nqi- ua tau zoo.

3. Integrated functions:Lub mezzanine chaw ua haujlwm tsim ua ke nrog chaw ua haujlwm thiab chaw cia khoom, txhim kho qhov chaw siv, zam qhov xav tau ntawm cov tsev ua haujlwm sib cais, thiab txo cov peev txheej tag nrho, uas tsim nyog rau cov neeg siv me thiab nruab nrab - loj hauv Philippines.

4. Zoo durability thiab adaptability rau lub zos huab cua:Cov khoom siv hlau yog galvanized (anti-} corrosion, haum rau huab cua hauv hiav txwv hauv Cebu thiab Manila) thiab cov cua louvers yog ua los ntawm aluminium alloy (anti-} corrosion), uas tuaj yeem ua rau lub neej kev pab cuam ntawm lub tsev khaws khoom; 50mm EPS sandwich vaj huam sib luag muaj kev ua haujlwm zoo thaum tshav kub kub rwb thaiv tsev, uas tsim nyog rau qhov siab - huab cua kub hauv Philippines.

Ntxiv rau, covkev tsim kho ceev ceevntawm CBC system tuaj yeem ua kom luv luv ntawm kev tsim kho, uas yog qhov zoo rau cov neeg siv khoom tso rau hauv kev siv sai li sai tau.
