Lub teeb Gauge Steel Structure Villa
12 hli Jason Plaster Board ntxiv rau 100 hli iav Fiber rwb thaiv tsev (Owens Corning) ntxiv rau 12 hli Jason Plaster Board (Ib txheej Fiber Cement Board es tsis txhob Plaster Board rau Phab Ntsa hauv Chav Dej)
Khoom Taw qhia
Main Ncej rau Lub Teeb Gauge Steel Structure Villa | ||
Lub teeb steel keel ncej | kg | G550 Al-Zn Galvanized, AZ150 |
Lub teeb steel keel ncej | kg | Q345 galvanized hlau |
Lub teeb steel keel ncej | kg | G550 Al-Zn Galvanized, AZ150, BlueScope hom |
Steel qauv | kg | Q235, Hwv |
Kho qhov system | ||
Ru Tsev System | ㎡ | 0.5mm Xim Hlau Glazed Pobzeb ntxiv rau 30mm XPS Rwb Thaiv Tsev Strip plus Ntoo batten ntxiv rau Lub Tsev Moisture-proof Tsev qhwv ntxiv rau 12mm OSB board ntxiv rau 150mm iav Fiber rwb thaiv tsev (Glass Fiber Owens Corning) |
㎡ | ||
m | ||
㎡ | ||
㎡ | ||
㎡ | ||
Sab nrauv phab ntsa System | ㎡ | 12 hli Eterpan planks ntxiv rau 30mmXPS Rwb thaiv tsev Sawb ntxiv Ntoo batten ntxiv rau 12 hli OSB Board ntxiv rau lub ru tsev Moisture-proof Housewrap ntxiv rau 12 hli Jason Plaster Board (Siv ib txheej 12 hli Fiber Cement Board es tsis txhob 12 hli Plaster Board rau sab hauv ntawm sab nrauv phab ntsa hauv chav dej) ntxiv rau 12 hli OSB board (Tsuas yog rau chav ua noj phab ntsa) |
㎡ | ||
m | ||
㎡ | ||
㎡ | ||
㎡ | ||
㎡ | ||
㎡ | ||
Sab Hauv Phab Ntsa System | ㎡ | 12 hli Jason Plaster Board ntxiv rau 100 hli iav Fiber rwb thaiv tsev (Owens Corning) ntxiv rau 12 hli Jason Plaster Board (Ib txheej Fiber Cement Board es tsis txhob Plaster Board rau Phab Ntsa hauv Chav Dej) |
㎡ | ||
㎡ | ||
Phab ntsa Ceramic Vuas rau Chav Dej | ㎡ | 300 * 450mm Phab ntsa pobzeb |
Pem Teb Board | ㎡ | 600 * 600mm (Ceramic, tsis suav nrog chav dej) |
㎡ | 300 * 300mm (Ceramic, tsuas yog suav nrog chav dej & chav dej) | |
㎡ | Ceramic pobzeb skirting kab | |
Floor deck plus stairs | ㎡ | 3m thickness, 1m dav |
㎡ | 18 hli Fiber Cement Board | |
㎡ | 100mm iav Fiber rwb thaiv tsev | |
㎡ | 12mm OSB board | |
㎡ | 300 * 300mm ceramic pobzeb (Anti-skid) | |
Qab nthab | ㎡ | 6 hli Fiber Cement board |
㎡ | 9 hli Jason Plaster Board Ceiling (xws li Thawj thiab Secondary Keel) | |
Qhov rai (AU, UL lossis EU tus qauv) | Aluminium Alloy Ncej Ob Chav iav Qhov rai, ua raws li AS2047 cov qauv, iav ua raws li AS / NZS2208, AS1288. | |
㎡ | ALU. zawv zawg qhov rai | |
Qhov rooj | pc ua | W920 * H2340mm ALU. viav vias qhov rooj |
pc ua | W820 * H2340mm MDF qhov rooj | |
pc ua | W820 * H2340mm MDF zawv zawg qhov rooj | |
Flashing & Ntug Trimming Fittings | ㎡ | Self-bending Xim Steel Sheet (Rov Ridge, Gable Phab Ntsa Wrapping Npog) |
Xim Steel Fascia | m | Xim Steel Verge Board (nrog Brackets) |
Aluminium Alloy Profiles | kg | Ntug npog rau kaum, qhov rooj & qhov rais, sab hauv kaum. |
12 hli Fiber Cement Board | ㎡ | kho kom zoo nkauj sab nraum zoov |
Accessory | ||
Kho vajtse Fittings | teeb | Lub teeb steel phab ntsa & ru tsev Accessories |
iav kua nplaum | teeb | |
Inlet & Outlet Drain System (AU, UL lossis EU tus qauv) | m | 80 * 80mm Aluminium Square Tube |
m | Aluminium Eave Gutter (nrog rau Accessories) | |
teeb | 1 Chav ua noj ntxiv rau 3 Chav Dej (Inlet & Outlet Dej Pipe & Accessories) | |
Chav dej System (AU, UL lossis EU tus qauv) | teeb | Xws li Ntxuav Basin, Phab ntsa mounted Sterilizer thiab Daim iav (xws li AU & WM Certificate) |
teeb | 1.5 * 0.9 * 2m (glazed ntxiv rau SS304 fittings) | |
teeb | 760 * 1670 hli | |
pc ua | Ceramic (WM Certificate) | |
Txee (AU, UL lossis EU tus qauv) | m | Txee Melamine Phaj Npog, Man-made pob zeb mesa (xim yog txiav txim los ntawm cov neeg siv khoom) |
pc ua | ||
pc ua | Xws li WM Certificate | |
Hluav taws xob (AU, UL lossis EU tus qauv) | teeb | 18 Lub Teeb 18 Hloov 24 Qhov (Sockets) 1 Lub Thawv Xa Khoom (nrog rau txhua qhov xav tau ntawm cov xaim thiab xaim, AC, lub rhaub dej kub, hluav taws xob kiv cua, Tel socket qhov) |
Qhov zoo
Lub neej rau cov qauv: 50 xyoo.
Av qeeg tsis kam: Max. ntau tshaj 8 qib.
Cua tsis kam: max 64m / s.
Hluav taws kub tsis kam: tag nrho cov khoom siv tuaj yeem tiv taus hluav taws.
Snow resistance: max 2.9KN / m² raws li xav tau
Thaum tshav kub kub rwb thaiv tsev: 100 hli nyob rau hauv thickness yuav phim 1 m thickness ntawm cib phab ntsa.
High acoustic rwb thaiv tsev: 60db ntawm sab nrauv phab ntsa 40db ntawm sab hauv phab ntsa
Kev tiv thaiv kab: Dawb los ntawm kev puas tsuaj los ntawm kab, xws li ntsaum dawb
Kev ua pa: kev sib xyaw ua ke ntawm qhov cua los yog cua tshuab ua kom cov cua hauv tsev tshiab thiab huv si
Ntim thiab xa khoom: 140SQM / 40'HQ thawv rau cov qauv nkaus xwb thiab 90SQM / 40'HQ thawv rau cov qauv nrog cov khoom siv kho kom zoo nkauj.
Kev teeb tsa: qhov nruab nrab yog ib tus neeg ua haujlwm ib hnub nruab ib SQM.
Daim ntawv qhia kev teeb tsa: xa engineer los qhia rau ntawm qhov chaw.
Daim ntawv thov
Lub teeb steel nyob hauv tsev;
Lub teeb steel tsev tsev;
Lub teeb steel pheej yig lub tsev;
Lub teeb steel khoom kim heev villa;
Lub teeb steel qauv tsev noj mov;
Lub teeb steel ncej chaw ua haujlwm lub tsev
Lub teeb steel ncej tsev so tsev;
Lub teeb steel ncej tsev kawm ntawv;
Lub teeb steel qauv tsev kho mob lub tsev;
Lub teeb steel qauv vocational resort tsev;
Lub teeb steel prefab granny tiaj tus;
Lub teeb steel ncej modular pod;
Lwm lub tsev prefab lub teeb yuag;
Tej yaam num
Lub npe qhov project | Damien lub tsev |
Sijhawm tiav | Xyoo 2017, Kaum Hli. |
Qhov Chaw Qhov Chaw | Coron Philippines |
Lub tsev | 280 m² os |
Qhov project piav qhia | Lub teeb Gauge Steel Structure Villa, hauv qab daus siv los ua ib lub rooj cob qhia me me rau Damien los kho lub Speedboat. Lub tsev no nyob hauv BBL chaw so. |
Lub npe qhov project | Raul's Apartment |
Sijhawm tiav | Xyoo 2019, Nov. |
Qhov Chaw Qhov Chaw | Coron Philippines |
Lub tsev | 430m wb |
Qhov project piav qhia | Tsim thiab muab tag nrho cov ntaub ntawv, muab cov lus qhia kev teeb tsa thiab kev txhawb nqa online, kuj muaj tus khub tsim kho zoo nyob ntawd los tswj tag nrho qhov project zoo heev. |
Lub npe qhov project | Youhan lub chaw ua haujlwm |
Sijhawm tiav | Xyoo 2020, Lub Peb Hlis |
Qhov Chaw Qhov Chaw | Manila |
Lub tsev | 300 m² os |
Qhov project piav qhia | Tsim thiab muab tag nrho cov ntaub ntawv, muab cov lus qhia kev teeb tsa thiab kev txhawb nqa online, siv rau kev muag khoom thiab lub tsev rau khoom me me. |
Lub npe qhov project | Tsev noj mov Buzz |
Sijhawm tiav | Xyoo 2019, Lub Xya Hli |
Qhov Chaw Qhov Chaw | Coron Philippines |
Lub tsev | 360 sq.m Modern Light Gauge Steel Prefab Lub Tsev |
Qhov project piav qhia | Tsim thiab muab txhua yam ntaub ntawv, muab cov lus qhia kev teeb tsa thiab kev txhawb nqa online, pab tus tswv tsim lub tsev noj mov hauv 4 lub hlis. |
Lub npe qhov project | Number 1 Homes Project |
Sijhawm tiav | Xyoo 2015, Lub Rau Hli |
Qhov Chaw Qhov Chaw | Christchurch NZs |
Lub tsev | 245sq wb |
Qhov project piav qhia | Peb tsim thiab muab ib qho kev daws teeb meem rau lub tsev no suav nrog kev cai ua huv, chav ua noj. Txhua tus ua tau raws li AU cov qauv. |
Lub npe qhov project | BBL Chaw Nyob Project |
Sijhawm tiav | Xyoo 2017 tsis tu ncua |
Qhov Chaw Qhov Chaw | Coron Philippines |
Lub tsev | 785 kwm |
Qhov project piav qhia | Ib thiab ob lub tsev hauv pem teb rau kev pab thiab kev pabcuam pej xeem rau BBL chaw so. |
Lub npe qhov project | Villa Dehaumont hauv Reunion |
Sijhawm tiav | Xyoo 2017 tsis tu ncua |
Qhov Chaw Qhov Chaw | Reunion Island |
Lub tsev | 147 sqm 3 lub tsev |
Qhov project piav qhia | Heavy cua loading thiab loj ncua. Peb pre-assembled tag nrho cov ncej steel rau yooj yim installation. |
Lub npe qhov project | Perth Project |
Sijhawm tiav | Xyoo 2015 |
Qhov Chaw Qhov Chaw | Perth UA |
Lub tsev | 268 m² os |
Qhov project piav qhia | Tsim thiab fabrication, ib qho kev daws teeb meem nrog rau txhua qhov chaw AU tus qauv. |
Lub npe qhov project | Chile Project |
Sijhawm tiav | Xyoo 2017 tsis tu ncua |
Qhov Chaw Qhov Chaw | South Chile |
Lub tsev | 1138 m² os |
Qhov project piav qhia | Kaum chav tsev ntawm Lub Teeb Gauge Steel Structure Villa, tsib txuas hauv ib kab, tsim tau zoo heev thiab zoo heev rwb thaiv tsev rau huab cua txias hauv zos. |
Lub npe qhov project | Moti Resorts Project |
Sijhawm tiav | Xyoo 2013 Lub Xya Hli |
Qhov Chaw Qhov Chaw | Nacala Mozambique |
Lub tsev | 3793 sqm nrog 48 chaw so |
Qhov project piav qhia | Ob chav pw nyob hauv Nacala ze ntawm hiav txwv puam, ib qho kev daws teeb meem nrog rau kev teeb tsa. |
Lub npe qhov project | Perth Project |
Sijhawm tiav | Xyoo 2016 |
Qhov Chaw Qhov Chaw | Perth UA |
Lub tsev | 3 08s qw |
Qhov project piav qhia | Tsim thiab fabrication, ib qho kev daws teeb meem nrog rau txhua qhov chaw AU tus qauv. |
FAQ
1. Koj puas muab kev pabcuam rau ntawm qhov chaw?
1) Tsuas yog tej yaam num loj muab kev pab cuam installation
2) Cov dej num dav dav, peb tuaj yeem muab kev qhia kev txhim kho raws li cov neeg siv khoom thov.
3) Kev saib xyuas kev teeb tsa tus qauv: 150USD / hnub, cov neeg siv khoom yuav tsum them tus nqi mus ncig, chaw nyob, tus nqi txhais lus, thiab ua kom cov neeg ua haujlwm noj qab haus huv thiab nyab xeeb.
2. Koj lub sijhawm xa khoom yog dab tsi?
Tus neeg muag khoom yuav lees paub lub sijhawm raws li, kev txiav txim loj yuav tsum sib txuas lus nrog kev tswj hwm kev txiav txim ua ntej. Feem ntau, lub sijhawm xa khoom yog 45 hnub tom qab tau txais qhov tso nyiaj. Lub sij hawm xa tuaj loj yuav tsum tau teem caij sib cais.
3.Yuav tswj qhov zoo ntawm koj cov khoom?
ib. Kev tsim qauv zoo: xav txog cov teeb meem uas yuav tshwm sim ua ntej thiab muab cov qauv tsim qauv zoo.
b. zoo ntawm cov khoom siv raw: xaiv cov khoom tsim nyog
c. Kev tsim khoom zoo: cov txheej txheem tsim khoom, cov neeg ua haujlwm paub txog, kev tshuaj xyuas nruj.
4. Yuav daws cov teeb meem zoo li cas?
Warranty yog 3 xyoos. Tsis pub dhau lub sijhawm lav, HANGZHOU XIXI BUILDING CO., LTD yuav lav tag nrho cov teeb meem zoo los ntawm kev tsim khoom.
5. Yog tias muaj kev pabcuam meej meej ntawm koj cov khoom? Yog muaj, ntev npaum li cas?
Raws li kev nyab xeeb thiab ib puag ncig, steel qauv tag nrho lub tsev 10 xyoo, lub ntsiab qauv 15 xyoo, tiv thaiv kab ke 10 xyoo.
6. Cov qauv tsim dab tsi koj muaj nyob rau hauv cov huab cua sib txawv (Yuav ua li cas cov khoom tuaj yeem coj mus rau cov huab cua sib txawv)?
Lub zog cua hauv cheeb tsam: txhim kho cov cua-tiv taus lub peev xwm ntawm cov qauv sab hauv.
Cov cheeb tsam txias: nce lub thickness ntawm phab ntsa, los yog siv cov khoom siv rwb thaiv tsev zoo, txhim kho kev tiv thaiv kev muaj peev xwm ntawm cov qauv.
Cov cheeb tsam corrosion siab: siv cov khoom siv tiv thaiv corrosion, los yog xim pleev xim rau txheej.
7. Koj tuaj yeem lav qhov zoo ntawm Lub Teeb Gauge Steel Structure Villa li cas?
A: Kev ua tau zoo yog yav tom ntej. Kev ua tau zoo yog qhov tseem ceeb tshaj plaws.
Peb muaj tsib tus neeg QC pab pawg tshuaj xyuas kev tsim khoom txhua hnub, lawv yuav ua raws li lub khw kos duab nruj me ntsis thiab tshawb xyuas txhua feem / project thaum pib, nruab nrab thiab rau cov khoom tiav.
Peb tuaj yeem sib sau ua ke qee chav nyob hauv peb lub Hoobkas rau qee qhov tshwj xeeb customized ua haujlwm kom paub tseeb tias txhua yam zoo txaus.
